Upgrade to Allegro

Cutting-Edge PCB Design

It’s not just CAD, it’s smarter than that

   Intelligent Design for Manufacturing

Allegro guides you through the process in real-time with features such as dynamic DFA, placement guidance, shape-based fillets, and a full suite of DFM rules, so you can avoid manufacturing errors before they happen.

   Proactive Signal Quality Design Capablities

Achieve peak signal quality performance with automated signal shielding, modeless indesign analysis for impedance, coupling, crosstalk, and IR drop, as well as automated return path analysis and more.

  Next-Generation Technology

Give yourself the capability to complete next-level design with features such as chip-on-board, tabbed routing, fiber-weave, embedded constraints, and more.

   Intuitive High-speed Design Capabilities

 Allegro’s auto-interactive delay and phase tune, auto rules-based routing, and reusable electrical rules sets provides unparalleled insight into your board and routes. With immediate design feedback, you can complete your designs up to 4x faster.

  Dynamic Collaboration and Planning

Effectively design and validate your flow plan with real-time shapes, multiple module and IP reuse features, and intelligent design planning, making rapid implementation of your final etch possible.
